Hikvision WiFi Doorbell With Inbuilt Wide Angle Camera

Web ID: 73

Hikvision DS-KB6003-WIP WiFi Video Door Bell Compact and Easy to install Video Intercom supporting audio & visual communication via mobile app
Manufacturer PN: DS-KB6403-WIP
Warranty: 3 Year
Manufacturer Website

Hikvision WiFi Doorbell With Inbuilt Wide Angle Camera 0
System Parameters
Operation System:   Embedded Linux Operation System
Processor:   High-Performance Embedded SOC Processor
Camera Parameters
Image Sensor:   CMOS 2MP HD Colorful Camera
Light sensitivity:   Low Illumination
Lens:   f1.96 mm, F 2.2
Field of view:   180° (Horizontal), 96°(Vertical)
Video Parameters
Video streaming:   Dual Stream
Main Stream: 1080P, Sub-Stream: VGA
Video Compression Standard:   H.264
Anti-flicker frequency:   50 Hz, 60 Hz
Wide dynamic range:   WDR
Audio Parameters
Audio Input:   Built-in Omnidirectional Microphone
Audio Output:   Built-in Loudspeaker
Audio streaming:   Two-Way, Full Duplex
Audio Compression Standard:   G.711 U
Audio Compression Rate:   64 Kbps
Audio Quality:   Noise Suppression and Echo Cancellation
Network Parameters
Network Protocol:   TCP/IP, RTSP
Interface number:   1 Wireless Interface (Wireless Network Card), Supporting 2.4 GHz
Light Supplement
Light Supplement Mode:   IR Supplement
Wavelength:   940 nm
Event actions
Event:   Motion Detection
Device Interfaces
TF Card (micro SD card):   Max. 128 G
Button:   1 Call Button, 1 Reset Button
Power Supply:   12 VDC
Power Consumption:   Max. 0.6 A
Power frequency:   50 Hz to 60 Hz
Working Humidity:   10% to 90%
Working Temperature:   -30° C to +50° C (-22° F to 122° F)
Dimensions(L × W × H):   122.4 mm x 45.9 mm x 28.1 mm (4.82" x 1.81" x 1.11")
IP Protection Level:   IP 54
